LG 49UH5J-H

LG 49UH5J-H

  • 49" (WxHxD mm): 1098,6 x 664,5 x 39,9
  • Nits: 500 cd/m²
  • Resolution: 4K, 3840 x 2160 @60Hz (4K UHD)
  • VESA: 300 x 300
  • Bezel: T 9,9 mm / B 14,4 LR 9,9 mm
  • Orientation: landscape, portrait
  • Weight: 15,4 kg
  • UH5 series
  • SKU:8806091657114
  • GTIN/EAN:8806091657114
  • MPN:49UH5J-H
Add To Favorite

You need to login to view the price.

View full details

New High Haze UHD Standard Signage


Proper Display Brightness


With a recommend brightness of 500 cd/m² for an indoor display, the UH5J-H series clearly deliver content and attract public attention, making it the most suitable display for marketing in meeting rooms, airports, retail, shopping malls etc.


High-Performance with webOS


LG webOS platform enhances user convenience with intuitive GUI and simple app development tools.


Conformal Coating


In various places the UH5J-H series is unable to avoid exposure to environments containing dust, humidity, etc. which may hamper performance over time. The conformal coating on power board reduces these risks by protecting UH5J-H series from salt, dust, iron powder, humidity, etc.


Mobile Content Management


You can create a store profile and get template recommendations using the Promota* app. Users can customize templates for all industries and easily create and manage content not only on PCs but also on mobile devices.


IP5x Certified Design


The IP5x Dust-Proof Certification ensures that the product is protected from dust, reducing the risk of performance degradation.


Compatible with AV Control System


The UH5J-H series has supported Crestron Connected for high compatibility with professional AV controls to achieve seamless integration and automated control*, boosting business management efficiency.

Display
Haze rate
28%
Panel type
IPS
Native refresh rate
60 Hz
Panel life
50000 h
Display number of colours
1.07 billion colours
Viewing angle, vertical
178°
Viewing angle, horizontal
178°
Contrast ratio (dynamic)
1000000:1
Contrast ratio (typical)
1000:1
Response time
8 ms
Native aspect ratio
16:9
Touchscreen
No
HD type
4K Ultra HD
Display brightness
500 cd/m²
Display resolution
3840 x 2160 pixels
LED backlighting type
Edge-LED
Display technology
LED
Display diagonal
124.5 cm (49")
Ports & interfaces
Infrared data port
Yes
RS-232C
Yes
Wi-Fi
Yes
Ethernet LAN (RJ-45) ports
1
Ethernet LAN
Yes
USB version
2.0
USB ports quantity
1
USB port
Yes
DisplayPorts in
1
DisplayPorts quantity
1
DVI-D ports quantity
1
DVI port
Yes
HDMI output ports quantity
1
HDMI input ports quantity
3
HDMI ports quantity
4
Audio
Built-in speaker(s)
Yes
Design
Bezel width (bottom)
1.44 cm
Bezel width (side)
9.9 mm
Bezel width (top)
9.9 mm
Panel mounting interface
300 x 300 mm
VESA mounting
Yes
Orientation
Horizontal/Vertical
Placement supported
Indoor
Product colour
Black
Product design
Digital signage flat panel
Performance
Open Pluggable Specification (OPS)
Yes
HDCP
Yes
HDCP version
1.4/2.2
International Protection (IP) code
IP5X
Operating hours (hours/days)
24/7
On Screen Display (OSD)
Yes
Number of OSD languages
21
On Screen Display (OSD) languages
Arabic, Simplified Chinese, Traditional Chinese, Czech, Danish, German, English, Spanish, French, Greek, Italian, Japanese, Korean, Portuguese, Swedish, Turkish
Picture-in-Picture
Yes
Multi-display supported
Yes
Purpose
Commercial
Power
Energy efficiency scale
A to G
Heat dissipation
342 BTU/h
AC input frequency
50 / 60 Hz
AC input voltage
100 - 240 V
Energy consumption (SDR) per 1000 hours
92 kWh
Energy efficiency class (SDR)
G
Power consumption (off)
0.5 W
Input voltage
100 -240 V
Power consumption (typical)
100 W
Computer system
Operating system installed
WebOS
Weight & dimensions
Weight (with stand)
16 kg
Height (with stand)
694.3 mm
Depth (with stand)
290 mm
Width (with stand)
1098.6 mm
Display weight
15.4 kg
Display height
644.5 mm
Display depth
39.9 mm
Display width
1098.6 mm
Packaging data
Package weight
18.8 kg
Package height
775 mm
Package depth
162 mm
Package width
1197 mm
Packaging content
Cables included
AC
Remote control type
IR
Remote control included
Yes
Operational conditions
Operating relative humidity (H-H)
10 - 80%
Operating temperature (T-T)
0 - 40 °C
Certificates
Certification
CB / NRTL FCC, KC
Technical details
Internal memory
16 MB
Sustainability compliance
Yes
Sustainability certificates
ENERGY STAR
Compliance certificates
CE
Other features
USB connector type
USB Type-A
