SoundTube Entertainment CM600I-WH

SoundTube Entertainment CM600I-WH

SoundTube 6.5" In Ceiling Speaker in White with a BroadBeam Tweeter, 69 Hz - 22 kHz, 90 W, 8 Ω, 88 dB

  • 90 W
  • 69 - 22000 Hz 8 Ω
  • Acrylonitrile butadiene styrene (ABS), Aluminium
  • Aluminium, White
  • SKU:CM600I-WH
  • GTIN/EAN:
  • MPN:CM600I-WH
Add To Favorite

You need to login to view the price.

View full details

SoundTube Entertainment CM600I-WH. Recommended usage: Universal. Connectivity technology: Wired. RMS rated power: 90 W, Frequency range: 69 - 22000 Hz, Impedance: 8 Ω, Sensitivity: 88 dB. Product colour: Aluminium, White

Patented BroadBeam™ waveguide technology delivers a consistent dispersion pattern for maximum intelligibility and edge-to-edge coverage. One 6.5 inch polypropylene woofer and one 1.0 inch convex aluminum tweeter with FerroFluid cooling mounted to a proprietary cast-aluminum motor-board and heat sink. Rapid-installation, blind-mount, fixed-wing mounting mechanism with constant-tension design affixing to ceiling thicknesses ranging from 0.25 inch (6.4 mm) to 1.69 inch (42.9 mm). Easy-access six-position selectable tap switch for 25-, 70.7- and 100-volt applications with a transformer bypass position. Separate tool-free magnetic grille and bezel assembly with integrated safety cable for ease of install and in-field painting. Steel grille with protective powder-coated finish for lasting durability. Average sensitivity of 88 dB offers high-output capabilities and reduced amplification costs. UL 1480 (UEAY) and 2043 approved.

Included accessories: Tile bridge, Euroblock connector, paint mask, conduit plate.

Loudspeakers
Woofer diameter (imperial)
16.5 cm (6.5")
Woofer
Yes
Tweeter diameter (imperial)
2.54 cm (1")
Tweeter
Yes
Speaker placement
In-wall/in-ceiling
Audio
Crossover frequency
3000 Hz
Sensitivity
88 dB
Impedance
8 Ω
Frequency range
69 - 22000 Hz
RMS rated power
90 W
Performance
Certification
CE, RoHS, UL1480A, UL2043
Housing material
Acrylonitrile butadiene styrene (ABS), Aluminium
Recommended usage
Universal
Product colour
Aluminium, White
Amplifier
Amplifier
No
Ports & interfaces
Bluetooth
No
Connectivity technology
Wired
Weight & dimensions
Weight
4.6 kg
Packaging data
Package weight
15.9 kg
Package height
482.6 mm
Package type
Box
Packaging data
Package depth
812.8 mm
Package width
355.6 mm
Packaging content
Manual
Yes
Quantity per pack
1 pc(s)
Sustainability
Sustainability certificates
CE, RoHS
