LG 75TR3PJ-B

LG 75TR3PJ-B

75'' UHD IR-Type Touch 3840x2160 60Hz 1200:1, HDMI RGB Audio In RS232C RJ45 USB 32GB, Wi-Fi, Android 8.0

  • Brightness : 390 nit (w/o Glass, Typ.)
  • Multi Touch Point : 20 Points (Max.)
  • Interface : HDMI (3), RGB (1), Audio In (1), RS-232C In (1), RJ45 (1), USB 3.0 Type A (3), USB 2.0 Type A (3), Audio Out / Optical Output, Touch USB (2)
  • SKU:8806091446244
  • GTIN/EAN:8806091446244
  • MPN:75TR3PJ-B.AEUQ
Add To Favorite

You need to login to view the price.

View full details

LG 75TR3PJ-B. Product design: Digital signage flat panel. Display diagonal: 190.5 cm (75"), Display technology: LED, Display resolution: 3840 x 2160 pixels, Display brightness: 390 cd/m², HD type: UHD+, Touchscreen. Wi-Fi. Operating hours (hours/days): 16/7. Operating system installed: Android 8.0. Product colour: Black

Multi Touch
The TR3DJ series can simultaneously use up to 20 points of multi touch. This function offers a lifelike board touch experience and makes collaboration much easier.

Enhanced Visibility with Low Parallax
With 1mm gap between the screen and tempered glass, which supports low parallax, The TR3DJ series can offer precise touch and excellent writing experience.

Dual Pen & Dual Color
The stylus pen comes in two different colors and with two different tip sizes of 3mm and 8mm. The dual pens enable users to write or draw simultaneously.

Easy Writing Experience
The TR3DJ series allows you to write and annotate on sources, so your writing experience can be easy and satisfying.

Air Class
Air Class supports connecting up to 30 students and offers interactive meetings for mobile devices on the same network, providing a variety of tools such as voting, answering, and sharing project texts. Air Class is easily accessible from the TR3DJ's main toolbar.

Built-in OPS Slot
The TR3DJ series supports OPS* slots, allowing you to easily and conveniently mount an OPS* device at the back of the digital board without the hassle of connecting to an external desktop, offering you more expanded functions.

ScreenShare Pro
ScreenShare Pro enables you to show up to six shared screens or a file on a screen in real-time, and it has enhanced usability by allowing users to share Chromecast and Apple device mirroring on the same network without any additional application.

Bluetooth Connectivity
TR3DJ supports Bluetooth wireless connections to various devices such as speaker, mouse, keyboard, etc. This is optimal for building a hybrid environment so that online and offline meetings and classes can proceed smoothly.

Web Browser
The TR3DJ series supports an embedded Android web browser, so you can search the web easily and quickly, without connecting to an external tablet or computer.

Toolbar
The Toolbar allows you to easily find and run the tool you need. The annotation feature works on virtually all file types, and you can highlight the section you wish to emphasize using the Spotlight function. The countdown and stopwatch features help you manage class time effectively.

Audio Experience
The TR3DJ series supports built-in speakers in both sides of the front bezel which deliver clear audio experience.

USB Block
USB Block Mode is a security measure that helps prevent data from being copied to unauthorized devices, which is essential for being used in spaces where security is critical.

Display
RGB colour space
NTSC
Panel type
IPS
Native refresh rate
60 Hz
Surface hardness
7H
Rated lifetime
30000 h
Display number of colours
1.07 billion colours
Viewing angle, vertical
178°
Viewing angle, horizontal
178°
Contrast ratio (typical)
1200:1
Response time
8 ms
Multi-touch
Yes
Touchscreen
Yes
HD type
UHD+
Display brightness
390 cd/m²
Display resolution
3840 x 2160 pixels
LED backlighting type
Direct-LED
Display technology
LED
Display diagonal
190.5 cm (75")
Ports & interfaces
OPS module slot
Yes
RS-232C
Yes
Audio (L/R) out
1
Audio (L/R) in
1
Wi-Fi
Yes
Ethernet LAN data rates
1000 Mbit/s
Ethernet LAN (RJ-45) ports
1
Ethernet LAN
Yes
USB ports quantity
6
USB port
Yes
HDMI version
2.2/1.4
HDMI ports quantity
3
Audio
RMS rated power
20 W
Number of built-in speakers
2
Built-in speaker(s)
Yes
Design
Bezel width (bottom)
4.57 cm
Bezel width (side)
1.89 cm
Bezel width (top)
1.89 cm
Anti-glare screen
Yes
Panel mounting interface
800 x 400 mm
VESA mounting
Yes
Screen shape
Flat
Orientation
Horizontal
Placement supported
Indoor
Product colour
Black
Product design
Digital signage flat panel
Performance
Open Pluggable Specification (OPS)
Yes
Operating hours (hours/days)
16/7
On Screen Display (OSD)
Yes
Browsing
Yes
Purpose
Universal
Power
AC input frequency
50 - 60 Hz
AC input voltage
100 - 240 V
Power consumption (off)
0.5 W
Power consumption (typical)
260 W
Computer system
Operating system installed
Android 8.0
Internal memory
32 GB
Computer system
Yes
Weight & dimensions
Weight
53.1 kg
Height
1020 mm
Depth
87 mm
Width
1710 mm
Packaging data
Package weight
69.8 kg
Package height
1140 mm
Package depth
280 mm
Package width
1860 mm
Packaging content
Cables included
AC, HDMI, USB Type-A to USB Type-B
Number of stylus pens
2
Stylus pen
Yes
Remote control included
Yes
Operational conditions
Operating relative humidity (H-H)
10 - 80%
Operating temperature (T-T)
0 - 40 °C
Features
Harmonized System (HS) code
85285210
