LG 22SM3G-B

LG 22SM3G-B

22SM3G-B, 21.5", IPS, 1920 x 1080 (FHD), 250 cd/m², USB Plug & Play, Built-in Wi-Fi

  • Brightness(Typ.) : 250 cd/m²
  • Bezel : 16.3mm
  • Depth : 53.8mm
  • Interface : HDMI(2) / USB 2.0 / RS232C / RJ45 / IR / Audio
  • USB Plug & Play, Built-in Wi-Fi
  • SKU:8806098661039
  • GTIN/EAN:8806098661039
  • MPN:22SM3G-B
Add To Favorite

You need to login to view the price.

View full details

LG 22SM3G-B Digital signage display 54.6 cm (21.5') IPS Wi-Fi 250 cd/m² Full HD Black Built-in processor 16/7. Product design: Digital signage flat panel. Display diagonal: 54.6 cm (21.5"), Display technology: IPS, Display resolution: 1920 x 1080 pixels, Display brightness: 250 cd/m², HD type: Full HD. Wi-Fi. Operating hours (hours/days): 16/7. Product colour: Black

22" Signage with More Utility for Commercial Space
22SM3G delivers information and performs guide with more effective ways in various commercial space, which provides more convenient solution thanks to its upgraded webOS platform.

High Performance SoC with webOS
Built-in Quad Core SoC can execute several tasks at once while providing smooth content playback without the need for a media player. Also, LG webOS smart signage platform enhances user convenience with intuitive GUI and simple app development tools.

Various Sensor Applications
LG webOS smart signage platform easily supports connections with external sensors such as GPIO, NFC/RFID, temperature sensors, etc, via USB plug-in. The overall cost for maintenance is reduced as there's no need to purchase additional software or media players.

A Wide Range of Interfaces
Through its diverse interfaces, users can connect the display with various sources for optimal use. Also, the failover function supports users preparing backup sources in case an unexpected error occurs.

USB Plug & Play
22SM3G supports USB Plug & Play feature, so users can easily set content playback using a USB.

Remote Monitoring and Control
Through the Control Manager, the embedded web monitoring solution, you can control and monitor the status of multiple 22SM3G displays in different locations in real-time. It is available on internet-connected devices, allowing you to flexibly and rapidly respond to emergency situations anywhere.

Real-time Care Service with LG Signage365Care
The maintenance gets easier and faster with the optional service Signage365Care*, a cloud service solution provided by LG service. It remotely manages status of displays in client workplaces for fault diagnosis and remote-control services, ensuring stable operation of the client’s business.

Warranty: 2 year

Display
Display diagonal (metric)
55.88 cm
Viewing angle, vertical
178°
Viewing angle, horizontal
178°
Contrast ratio (dynamic)
400000:1
Contrast ratio (typical)
1000:1
Native aspect ratio
16:9
Touchscreen
N
HD type
Full HD
Display brightness
250 cd/m²
Display resolution
1920 x 1080 pixels
Display technology
IPS
Display diagonal
54.6 cm (21.5")
Ports & interfaces
RS-232C
Y
RS-232 interface
Y
Audio (L/R) in
1
Wi-Fi
Y
Ethernet LAN (RJ-45) ports
1
Ethernet LAN
Y
USB version
2.0
USB ports quantity
1
USB port
Y
DVI port
N
HDMI ports quantity
2
Audio
RMS rated power
2 W
Number of built-in speakers
2
Built-in speaker(s)
Y
Design
Panel mounting interface
100 x 100 mm
VESA mounting
Y
Orientation
Horizontal
Product colour
Black
Product design
Digital signage flat panel
Performance
Operating hours (hours/days)
16/7
Purpose
Universal
Power
Heat dissipation
7.89 BTU/h
AC input frequency
50/60 Hz
AC input voltage
100 - 240 V
Power consumption (off)
0.5 W
Power consumption (sleep)
1 W
Power consumption (standby)
30 W
Power consumption (typical)
33 W
Computer system
Internal memory
4 GB
Processor cores
4
Built-in processor
Y
Computer system
N
Weight & dimensions
Weight
3.34 kg
Height
302.1 mm
Depth
53.8 mm
Width
510.3 mm
Packaging data
Package weight
3.5 kg
Package height
357 mm
Package depth
103 mm
Package width
565 mm
Packaging content
Mounting kit
Y
Cables included
AC
Remote control included
Y
Operational conditions
Storage relative humidity (H-H)
5 - 85%
Storage temperature (T-T)
-20 - 60 °C
Operating relative humidity (H-H)
10 - 80%
Operating temperature (T-T)
0 - 40 °C
Certificates
Certification
CB, NRTL, EMC, FCC Class "A", CE, ErP
Features
Harmonized System (HS) code
85285210
